922M-3 Mini Lever Connector

2 to 5 and 8 Poles available

Extreme tiny size for space saving

Test slot provided

Transparent housing for visible connetion

产品详情

Datasheet

Model	Pole	Dimensions (Unit:mm)	Rating & Wiring range	Material	Certifications
922M-2	2 Pole	17.512.69.2	450V/24A, T85, 0.2-2.5mm2	PC 94V-2 housing PA66 94V-2 Lever Brass / Tin-plated/ stainless steel nsert	CE, ENEC, ROHS, REACH
922M-3	3 Pole	17.517.69.2
922M-4	4 Pole	17.522.69.2
922M-5	5 Poel	17.526..79.2
922M-8	8 Pole	17.542.69.2
922-2	2 Pole	191411	IEC 450V/32A; T85; 0.2-4.0mm2; UL 600V/32A,T105, AWG 28-12		CE,ENEC,UL, KEMA KEUR, N, ROHS, REACH
922-3	3 Pole	1919.611
922-4	4 Pole	1925.211
922-5	5 Pole	1930.811

Drawing

Why choose us?

🔹 Special offer: Exclusive free samples for partners

🔹 Certifications & Compliance:

Safety Approvals: UL, VDE, CE, ENEC, SAA, CQC，TUV, KEMA KEUR

Environmental Compliance: RoHS, REACH

🔹 We own complete import/export privileges - no middlemen needed for faster delivery and better pricing!

🔹 Value-Added Procurement Services

One-stop electronic component sourcing

72-hour emergency order response
